Rod Magnet

  • Powerful and Reliable
  • Up to 14000 Gauss on the stainless steel protective cover
  • Magnets N54
  • Polished Design
  • Diameter of the rod magnet : 25mm, 32mm, 38mm, 50mm.
  • Can be customized
Availability:
Product Description

The rod magnet is made of rare earth permanent, coated with stainless steel tube and are seal-welded. By using its power magnetic force, small ferromagnetic impurity could be picked up in various powder and pulp, thus improving the purity of materials, to upgrade products’ quality and protecting the downstream equipment. Rod Magnet could be fixed separately in the feed port and discharging port or used in the pipeline, and could also be used to manufacture complete sets of the magnetic grid, magnetic drawer, magnetic liquid traps, magnetic rotary separator.


Specifications

Model

Surface Gauss

Surface Material

Diameter

Length

Ends Style

Working Temperature

TX-25

2000---12000 Gs

SUS304 SUS316

D25MM

100-1500MM

Flat, Inner or Outer Screw, or on request

< 300℃

TX-30

2000---12000 Gs

SUS304 SUS316

D30MM

100-2000MM

Flat, Inner or Outer Screw, or on request

< 300℃

TX-32

2000---12000 Gs

SUS304 SUS316

D32MM

100-2000MM

Flat, Inner or Outer Screw, or on request

< 300℃

TX-38

2000---12000 Gs

SUS304 SUS316

D38MM

100-2000MM

Flat, Inner or Outer Screw, or on request

< 300℃

TX-50

2000---12000 Gs

SUS304 SUS316

D50.8MM

100-2000MM

Flat, Inner or Outer Screw, or on request

< 300℃


Advantages

Stable and long lifetime

Peak Gauss over 12000 Gauss

Welded with Watertight

Temperature resistance up to 300℃


External thread Internal thread Ring
Hand grip Special Special



Data required for inquiry :

Dimension or drawing

Working temperature

Surface magnetic force

Thread holes model / one end or both ends (M6,M8,M10,M12...)

Quantity

Other requirements
