High-Performance Neodymium Magnets (NdFeB) Manufacturer in China

Neodymium (NdFeB) magnets are rare-earth permanent magnets known for their exceptional magnetic strength and compact size. Compared to ferrite and Alnico, NdFeB magnets provide 5–15 × higher energy density, making them ideal for miniaturized designs. Since their invention in 1983, sintered neodymium magnets have become the cornerstone of modern magnetic applications.

At Shanghai Taixiong Magnetic Industry Co., Ltd, we specialize in OEM & custom magnet production, offering full support from material selection to final coating, packaging, and global delivery.

Sintered Neodymium Iron Boron Magnets Introduced in 1983, the Sintered Neodymium Iron Boron (NdFeB) magnet stands as a remarkable innovation primarily composed of neodymium, iron, and boron. Its intrinsic coercivity far surpasses that of ferrite by a remarkable margin of 5-10 times, and exceeds aluminum-nickel-cobalt by a remarkable margin of 6-10 times. Remarkably, it boasts a maximum energy product that is a staggering 5-15 times greater than ferrite, firmly establishing it as the pinnacle of contemporary magnetic materials. In comparison with conventional magnetic materials, it not only exhibits exceptional magnetic properties but also stands out for its remarkable cost-effectiveness, thereby unlocking an extensive array of possibilities for magnetic material applications. Customized dimension, grade and design are welcome. Contact : Yingyun@taixiongmagnet.com

Disc Magnet

Ring Magnet

Block Magnet

Arc Magnet

Special Shape Magnet

Radial Ring Magnet

Dy/Tb Diffusion Magnet

Multipole Ring Magnet

Available Shapes

Disc, Ring, Block, Arc, Countersunk, Custom

Shape	Drawing	Specification	Biggest Size (mm)
Block		L	≤250
		W	≤250
		T	≤60
Disc		D	≤300
		T	≤60
Ring		D	≤300
		d	≤240
		T	≤60
Arc		L	≤220
		W	≤150
		T	≤60
		a	0-180°

Magnetization Direction

Common direction of magnetization showed in picture bellows:

1> Disc, cylinder and ring shape magnet can be magnetized axially or diametrically.

2> Rectangle shape magnets can be magnetized through thickness, length, or width.

3> Arc shape magnets can be magnetized diametrically, width or thickness.

We provide full customization services, including:

• Shape & size (up to 300 mm diameter)

• Magnetization direction

• Coating & corrosion resistance treatment

• Assembly with metal parts or plastic injection

• Prototyping & small-batch sample runs

Packaging and logistics

All magnets are vacuum-packed to avoid corrosion and are shipped in shock-proof, export-standard cartons.

Lead Time: 15–20 days

Shipping Options: Air, Sea, Express (DHL, FedEx)

MOQ: 10 pcs

Samples: Available on request

Quality and certification

All products comply with ISO 9001, RoHS, and REACH standards. Each batch undergoes strict testing for:

– Magnetic flux density

– Coating adhesion

– Dimensional accuracy

– Thermal aging resistance

FAQ

Q1: Can I get a custom-shaped neodymium magnet?

A1: Yes, we support CNC machining and custom tooling for all shapes and magnetization patterns.

Q2: What coating should I choose?

A2: NiCuNi for general use, Epoxy for humid environments, and Zinc for cost-effective options.

Q3: Do you offer multi-pole ring magnets?

A3: Yes, we produce multi-pole rings with up to 24 poles, widely used in BLDC motors.
